Observe and Obey:
Repair procedures shall be completed by a
person trained and qualified on the repair of this
machine.
Immediately tag and remove from service a
damaged or malfunctioning machine.
Repair any machine damage or malfunction
before operating the machine.
Before Repairs Start:
Read, understand and obey the safety rules
and operating instructions in the Genie Z-60/34
Operator's Manual.
Be sure that all necessary tools and parts are
available and ready for use.
Read each procedure completely and adhere
to the instructions. Attempting shortcuts may
produce hazardous conditions.
Unless otherwise specified, perform each
repair procedure with the machine in the
following configuration:
· Machine parked on a firm, level surface
· Boom in stowed position
· Turntable rotated with the boom between
the non-steer wheels
· Turntable secured with the turntable
rotation lock
· Key switch in the off position with the
key removed
· Wheels chocked
Part No. 75861

Repair Procedures

About This Section
Most of the procedures in this section should only
be performed by a trained service professional
in a suitably equipped workshop. Select the
appropriate repair procedure after troubleshooting
the problem.
Perform disassembly procedures to the point
where repairs can be completed. To re-assemble,
perform the disassembly steps in reverse order.
Symbols Legend
Indicates that a specific result is expected after
performing a series of steps.
Genie Z-60/34
Section 4 • Repair Procedures
Safety alert symbol—used to alert
personnel to potential personal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Red—used to indicate the
presence of an imminently
hazardous situation which, if not
avoided, will result in death or
serious injury.
Orange—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.
Yellow with safety alert symbol—
used to indicate the presence of a
potentially hazardous situation
which, if not avoided, may cause
minor or moderate injury.
Yellow without safety alert
symbol—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, may result in property
damage.
Green—used to indicate operation
or maintenance information.
4 - 1
