Primary Boom Components; Cable Track - Genie Z-60/34 Service Manual

November 2003
REV A
4-1

Cable Track

The primary boom cable track guides the cables
and hoses running up the boom. It can be repaired
link by link without removing the cables and hoses
that run through it. Removing the entire primary
boom cable track is only necessary when
performing major repairs that involve removing the
primary boom.
How to Remove the Cable Track
When removing a hose assembly
or fitting, the O-ring on the fitting
and/or hose end must be replaced
and then torqued to specification
during installation.
Refer to Section 2, Hydraulic Hose
and Fitting Torque Specifications.
1 Raise the jib boom slightly and place blocks
under the platform mounting weldment. Then
lower the jib boom until the platform is resting
on the blocks just enough to support the
platform.
Do not rest the entire weight of the
boom on the blocks.
2 Locate the cables from the primary boom cable
track to the platform control box. Number each
cable and its entry location at the platform
control box.
Part No. 75861

Primary Boom Components

3 Disconnect the cables from the platform control
4 Tag, disconnect and plug the hydraulic hoses
5 Pull the slave cylinder hydraulic hoses out of
6 Tag and disconnect the wiring from the
7 Remove the cable clamp from the platform
8 Remove the cable cover from the side of the jib
9 Tag, disconnect and plug the hydraulic hoses
Genie Z-60/34
Section 4 • Repair Procedures
box.
If your machine is equipped with
an air line to platform option, the
air line must be disconnected from
the platform before removal.
from the platform leveling slave cylinder. Cap
the fittings on the slave cylinder.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
the protective sheath.
jib boom/platform rotate manifold.
rotator.
boom.
from the jib boom/platform rotate manifold.
Cap the fittings on the jib boom/platform rotate
manifold.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
4 - 15
