Section 3 • Scheduled Maintenance Procedures
CHECKLIST E PROCEDURES
E-3
Perform Engine Maintenance -
Deutz Models
Deutz engine specifications require
that this procedure be performed
every 3000 hours.
Proper engine maintenance, following the engine
manufacturer's maintenance schedule, is essential
to good engine performance and service life. Failure
to perform the maintenance procedures can lead to
poor engine performance and component damage.
Required maintenance procedures and additional
engine information are available in the
Deutz FL 1011F Workshop Manual
(Deutz part number: 0297 7195).
Deutz FL 1011F Workshop Manual
Genie part number
To access the engine:
1 Remove the two engine pivot plate retaining
bolts. Swing the engine pivot plate out away
from the machine and secure it from moving.
Crushing hazard. Failure to secure
the engine pivot plate from moving
could result in death or serious
injury.
3 - 50
E-4
Grease the Steer Axle
Wheel Bearings, 2WD Models
Maintaining the steer axle wheel bearings is
essential for safe machine operation and service
life. Operating the machine with loose or worn
wheel bearings may cause an unsafe operating
condition and continued use may result in
component damage. Extremely wet or dirty
conditions or regular steam cleaning and pressure
washing of the machine may require that this
procedure be performed more often.
1 Loosen the wheel lug nuts. Do not remove them.
2 Block the non-steering wheels, then center a
lifting jack under the steer axle.
3 Raise the machine 6 inches / 15 cm and place
blocks under the drive chassis for support.
52229
4 Remove the lug nuts. Remove the tire and wheel
assembly.
5 Check for wheel bearing wear by attempting to
move the wheel hub side to side, then up and
down.
Result: There should be no side to side or up
and down movement.
Skip to step 10 if there is no movement.
Genie Z-60/34
November 2003
REV A
Part No. 75861
