Hardware Installation and Reference Guide
Off N/A
Blinking green 3Hz
Blinking red 3Hz
Solid blue N/A
Breathing blue Gradually fading
Solid red N/A
Double blinking 3Hz (on and off for
red 2 cycles
alternately)

1.4 Power Sources

The AP can be powered either with a power adapter or through Power over Ethernet (PoE).
To use a PoE device, make sure it supports the IEEE 802.3af/at PoE standard.

1.5 Cooling Solution

The AP adopts fanless design.
Leave sufficient space surrounding the AP when installing the AP to permit proper airflow for ventilation.

1.6 Radiation Pattern

The RG-AP740-I uses Ruijie's patented X-Sense Smart Antenna. Regardless of the high mobility of smart devices, the AP
always provides the best signal path. Three radio patterns are shown in the following disgrams. The antennas focus gains
in front of the AP, so the signal strength in the front is stronger. It is preferable to install the AP towards the area that
requires the best wireless coverage.
When mounting the AP on a wall or ceiling, install the AP towards where you stand to avoid backward coverage.
Install the AP in a way that maximizes coverage.
When installing the AP indoors, it is better to mount it on the ceiling for greater coverage rather than on the wall.
Figure 1-2 and Figure 1-3 show the preferred wall-mount and ceiling-mount orientations of the AP operating in the 2.4
GHz and 5 GHz bands, respectively.
Figure 1-2 Preferred Ceiling-Mount and Wall-Mount Orientations of the RG-AP740-I (in the 2.4 GHz Band)
The AP is NOT receiving power or in the Silent mode. This mode can be
disabled by software.
Initialization is in progress. Continuously blinking green indicates abnormal
operation.
Initialization is complete, but the Ethernet port is not connected.
Normal operation, but no wireless clients are associated with the AP.
Normal operation, at least one wireless client is associated with the AP.
Warnings(defined by software)
Locate AP.
