Hardware Installation and Reference Guide
Figure 3-10 Removing the Wall Mount AP
3. If the AP is installed on the ceiling, hold the AP in your hands and push it sideways. Attempt to push it in four
directions (the AP can be pushed out only in one direction).
Figure 3-11 Removing the Ceiling Mount AP

3.7 Connecting Cables

Connect the UTP/STP to the LAN1/PoE port on the AP. See Appendix A for the supported wiring for twisted pairs.
By default, the baud rate is set to 9600, data bit 8, parity none, stop bits 1 and flow control none on the AP console
port. The console port is used only when you want to configure the AP manually.
Avoid bending the cable in a small radius close to the connector.
Ruijie recommends that you do not use Ethernet cables with protective sleeves as they could make installation of
Ethernet cables more difficult.

3.8 Bundling Cables

Precautions
Installing the Access Point
·
