Remarks
④
1000BASE-T/100BASE-TX/10BASE-T auto-sensing Ethernet port (PoE-capable)

1.3 Power Sources

The AP can be powered either with a power adapter or through Power over Ethernet (PoE).
To use a PoE device, make sure it supports the IEEE 802.3af/at PoE standard.

1.4 Cooling Solution

The AP adopts fanless design.
Leave sufficient space at the surrounding of the AP when place the AP to permit airflow for proper ventilation.

1.5 Radiation Pattern

Because the antennas focus gains in front of the AP, signal strength in the front is stronger. Therefore, it is preferable to
install the AP towards the area where wireless coverage is most required.
When mount the AP on a wall or ceiling, install the AP towards where you stand to avoid backward coverage.
It is preferable to install the AP in a way that maximizes coverage.
When install the AP indoors, it is better to mount it on the ceiling rather than on the wall because the AP provides
greater coverage when it is installed on the ceiling.
Figure 1-3 and Figure 1-4 show the preferred wall-mount and ceiling-mount orientations of the AP operating in the 2.4
GHz and 5 GHz bands, respectively.
Figure 1-3 Preferred Ceiling-Mount and Wall-Mount Orientations of the RG-AP530-I V2 (in the 2.4 GHz Band)
·
