Hardware Installation and Reference Guide
2. Align the square feet on the rear of the AP over the mounting holes on the bracket. See Figure 3-5.
Figure 3-5 Aligning the Square Feet with the Mounting Holes
Install the Ethernet cables before mounting the AP on the bracket.
3. Slide the AP into the holes in the reverse direction against the arrow on the mounting bracket until it clicks into place.
Note: keep the Ruijie logo pointed upwards. See Figure 3-6.
Figure 3-6 Mounting the AP on the Bracket
When mounting the AP on the wall, keep the Ruijie logo pointed upwards.
The square feet should fit easily into the mounting slots. Do not forcibly push the AP into the slots.
After installation, verify that the AP is securely fastened.

3.5 (Optional) Securing the Access Point

1. Loosen the screw on the mounting bracket and enable the hidden lock.
Figure 3-1 Enabling the Hidden Lock
Installing the Access Point
·
