Removing The Access Point - Ruijie RG-AP740-I Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
2. Align the square feet on the rear of the AP over the mounting holes on the bracket, slide the AP in the reverse
direction against the arrow on the mounting bracket until it clicks into place.
Figure 3-2 Mounting the AP on the Bracket
Before mounting the AP on the bracket, you must first install the Ethernet cables.

3.6 Removing the Access Point

1. If the hidden lock is enabled, attach the front part of the key to the edge of the mounting bracket (keep the Ruijie key
logo towards the top panel of the AP). Slide the key along with the four edges of the mounting bracket, and attempt
to insert the key into the keyhole. It can only be inserted into one marked keyhole.
Figure 3-9 Inserting the Key for Unlocking
2. If the AP is installed on the wall, hold the AP in your hands and push it upward and away from the bracket in the LAN
port direction.
Installing the Access Point
·
