Reset Button; Power Sources; Cooling Solution - Ruijie RG-AP180 Series Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
Fast blinking 2.5Hz (fast
green before blinking green)
solid green
Fast blinking 2.5Hz
red
Blinking orange 1Hz
Blinking green 1Hz
Slow blinking 0.4Hz
green

1.4 Reset Button

To reset the AP, you need to keep the reset button pressed for 2s or less.
To restore default settings, you need to keep the reset button pressed for 3s or more.

1.5 Power Sources

RG-AP180 supports two power supply modes: PoE and DC power supply.
PoE power supply:

Input voltage range: 44-57V

Rated current: 0.3A
When adopting PoE power supply, make sure the peer end also supports 802.3af/802.3at.
DC power supply:

Input voltage range: 12V

Rated current: 1A

1.6 Cooling Solution

The AP adopts fanless design. Keep enough space around the device to guarantee airflow for proper ventilation.
software.
Initialization is in progress. The AP is operational.
Firmware upgrade in progress. Do not power off the AP.
AP is operational and Ethernet link is down.
AP is operational and Ethernet link is up. CAPWAP error.
AP is operational and CAPWAP connection is established. At least one client is
associated.
Product Overview
·
