Hardware Installation and Reference Guide

1 Product Overview

The RG-AP740-I AP uses Ruijie's highly acclaimed X-Sense Smart Antenna and tops the class by supporting 802.11ac
Wave 2. Featuring nine spatial streams and MU-MIMO, the AP implements a leading tri-radio, dual-band design. The
three main radios deliver up to 1,734Mbps+800Mbps+433Mbps access rates and the third offers frequency spectrum
scanning. The whole AP speeds performance up to 2,967Mbps. The market-leading X-Sense Smart Antenna provides
better coverage and ensures the best access for mobile terminals. All models in the X-Sense AP Series support security,
radio frequency (RF) control, mobile access, Quality of Service (QoS) and seamless roaming. Teamed up with the Ruijie
RG-WS Wireless Controller Series, wireless data forwarding, high performance security and access control can be
accomplished with ease.
In addition, the RG-AP740-I AP (with tri-band and dual-radio design) flexibly supports 2.4G+5G+2.4G or 2.4G+5G+5G
working modes and concurrently 802.11ac Wave 2, 802.11ac Wave 1 and 802.11n. The AP can be mounted on a ceiling
or wall or on a pole. The AP supports local power supply and PoE to meet challenges in a wide variety of deployment
scenarios, including large-scaled campuses, enterprises, hospitals and WiFi hotspots.

1.1 Technical Specifications

Table 1-1 RG-AP740-I Technical Specifications
Model
RF
Transmission
Protocol
Operating Bands
Antenna
Spatial Streams
Working Bandwidth
Max Throughput
Modulation
Receive Sensitivity
RG-AP740-I
Tri-band, dual-radio
Three radio frequency cards support concurrent 802.11a/b/g/n, 802.11ac Wave 1 and 802.11ac
Wave 2.
Operating modes of 2.4G+5G+2.4G and 2.4G+5G+5G operating modes are supported.
802.11b/g/n: 2.4GHz to 2.483GHz
802.11a/n/ac: 5.15GHz to 5.35GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.85GHz
(Country-Specific)
X-Sense Smart Antenna array
Built-in
9 streams: 4x4 SU-MIMO, 4x4 MU-MIMO, 1x1 SISO
HT160(80+80), HT80, HT40, HT20
802.11b/g/n: up to 800Mbps
802.11a/n/ac: up to 1,734Mbps and 433Mbps
Up to 2,967Mbps per AP
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM and 256QAM
11a: -88dBm (6Mbps), -79dBm (24Mbps), -77dBm (36Mbps), -73dBm (54Mbps)
11b/g: -88dBm (6Mbps), -79dBm (24Mbps), -77dBm (36Mbps), -73dBm (54Mbps)
11n: -86dBm@MCS0, -68dBm@MCS7, -86dBm@MCS8, -68dBm@MCS15
11ac HT20: -83dBm (MCS0), -64dBm (MCS8)
11ac HT40: -80dBm (MCS0), -58dBm (MCS9)
11ac HT80: -77dBm (MCS0), -52dBm (MCS9)
11ac HT160(80+80): -74dBm (MCS0), -50dBm (MCS9)
