Disc Sanding

The sanding disc can be used to smooth the ends
of workpieces.
To reduce the risk of your fingers getting
trapped between the work table and sand-
ing disc, make sure the table is approxi-
mately ⁄ " away from the sanding disc.
1
16
Always keep the workpiece on the left side of
the wheel that rotates down toward the work
table. This will keep the workpiece from fly-
ing out of your hands due to kickback.
To use the sanding disc:
1. DISCONNECT SANDER FROM POWER!
2.
Adjust the angles of the work table and the
miter gauge for your operation.
3. Connect the sander to power, turn it ON, and
allow it to reach full speed.
4. Place the workpiece on the work table and
firmly against the miter gauge.
5.
Slowly, and with light pressure, move the
workpiece into the left side of the sanding
disc. See Figures 54–57 for examples of disc
sanding.
Figure 54. Example of 90° disc sanding.
-36-
Figure 55. Example of miter sanding.
Figure 56. Example of angle sanding.
Figure 57. Example of sanding round workpiece.
Note: To prevent burning the workpiece and over-
loading the sanding disc, move the workpiece
slowly back and forth from the left side of the
sanding disc to the center.
Model G1014Z/G1014ZX (Mfd. Since 07/17)
