COMBINATION SANDER
MODEL G1013
INSTRUCTION MANUAL
COPYRIGHT © 1991 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED FEBRUARY, 2002. PRINTED IN TAIWAN
ONLINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE
MACHINE CONFIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE
MACHINE, THIS MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS
ABOUT DIFFERENCES. PREVIOUS VERSIONS ARE NOT AVAILABLE ONLINE.

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G1013

Summary of Contents for Grizzly G1013

  • Page 1 INSTRUCTION MANUAL COPYRIGHT © 1991 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. REVISED FEBRUARY, 2002. PRINTED IN TAIWAN ONLINE MANUAL DISCLAIMER THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED.
  • Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...

  • Page 3: Table Of Contents

    SAFETY SAFETY INSTRUCTIONS FOR POWER TOOLS ...2-3 ADDITIONAL SAFETY INSTRUCTIONS FOR SANDERS ...4 CIRCUIT REQUIREMENTS 110V OPERATION ...5 FUSING ...5 EXTENSION CORDS ...5 GROUNDING ...5 INTRODUCTION COMMENTARY ...6 UNPACKING...7 PARTS INVENTORY ...8 CLEAN UP ...9 SITE CONSIDERATIONS ...9 ASSEMBLY OVERVIEW...10 ASSEMBLY PROCESS...10-13 ADJUSTMENTS BELT TRACKING ...14...

  • Page 4: Safety

    G1013 Combination Sander VISITORS...
  • Page 5 13. NEVER OVERREACH. Keep proper foot- ing and balance at all times. G1013 Combination Sander 14. MAINTAIN TOOLS WITH CARE. Keep 15. DISCONNECT TOOLS before servicing 16. REDUCE THE RISK OF UNINTENTION- LENGTH 17.

  • Page 6: Additional Safety Instructions For Sanders

    Like all power tools, there is danger asso- ciated with the Model G1013 Combination Sander. Accidents are frequently caused by lack of familiarity or failure to pay atten- tion. Use this tool with respect and cau- tion to lessen the possibility of operator injury.

  • Page 7: Circuit Requirements

    Extension Cords If you find it necessary to use an extension cord with the Model G1013, make sure the cord is rated Hard Service (grade S) or better. Refer to the chart in the standard safety instructions to determine the minimum gauge for the extension cord.

  • Page 8: Introduction

    Grizzly’s commitment to customer satis- faction. The Model G1013 is a combination 1" x 42" belt and 8" disc sander that is capable of a wide vari- ety of operations. The 1" wide belt enables you to sand small or finely-detailed pieces as well as the inside areas of closed loops.

  • Page 9: Unpacking

    Customer Service. G1013 Combination Sander When you are completely satisfied with the con- dition of your shipment, you should inventory its parts.

  • Page 10: Parts Inventory

    A full parts list and breakdown drawing can be found toward the end of this manual. For easier assembly, or to identify missing parts, please refer to the detailed illustra- tions at the end of the manual. G1013 Combination Sander...

  • Page 11: Clean Up

    G1013 Combination Sander Site Consideration BENCH LOAD Your Model G1013 Combination Sander repre- sents a relatively large weight load in a small foot- print. Be sure that you workbench is adequately reinforced to support the weight of the sander.

  • Page 12: Assembly

    Figure 4. Sanding unit mounted on base. ⁄ " - 20 x 1" hex bolts, four ⁄ " - 20 hex ⁄ " - 18 x ⁄ " hex bolts, eight (8) ⁄ " - 18 hex G1013 Combination Sander...
  • Page 13 (4) ⁄ sure that the bolts protrude upward through the motor base. See Figure 6. Finger tighten only. Figure 6. Motor mounted on base. G1013 Combination Sander ⁄ " hex bolts, ⁄ " - 18 ⁄ "...
  • Page 14 - 20 wing nuts. See Figure 12. Figure 12. Disc table attachment. ⁄ '' square key. ⁄ " - 20 x ⁄ '' setscrew. ⁄ " - 20 x 1 ⁄ " carriage ⁄ " flat washers and two (2) ⁄ G1013 Combination Sander "...
  • Page 15 DO NOT attempt to connect or adjust wiring with the cordset plugged into its power source. Serious danger of electrocution could result. G1013 Combination Sander ⁄ '' gap 15. Wire the motor by removing the motor junc- tion box cover and feed the power cord from the switch through the plastic grommet at the bottom of the junction box.

  • Page 16: Adjustments

    Remove the Sanding Belt Table and Sanding Belt Guards. Turn the 8'' disc by hand to observe lateral belt drift. DO NOT turn the sander on to inspect for belt drift. By sight, center the Sanding Belt by adjust- ing the tracking knob. See Figure 15.

  • Page 17: Belt Table Tilt

    Loosen the hex nut as shown in Figure 18. Tilt the table to the desired position. Tighten the hex nut. Figure 18. Belt table in tilted position. G1013 Combination Sander Belt Replacement Once you have turned off the switch and discon- nected the sander from its power source: Remove the two Sanding Belt Guards.

  • Page 18: Disc Table Tilt

    Aluminum Disc from the Motor Shaft because the Sanding Disc cannot be peeled off or the Aluminum Disc requires cleaning. Do not use petroleum-based solvents to clean the surface of the aluminum disc. This adversely affects adhesion. G1013 Combination Sander...

  • Page 19: Operations

    Using this Never use the Model G1013 for applications other than those for which it was made. DO NOT overload the machine or use excess force when sanding. Severe personal injury, damage to the machine, or damage to your workpiece could occur.

  • Page 20: General Sanding

    Roller rearward so the workpiece will not be acci- dentally forced against it. Slowly feed the work- piece into the belt; the belt will follow the contour of the workpiece. See Figure 20. Figure 20. Contour sanding. G1013 Combination Sander...

  • Page 21: Inside Sanding

    Replace guards and table. Adjust belt tracking as described in Adjustments section. Figure 21. Belt arrangement for inside sanding. G1013 Combination Sander Sharpening Tilt the table to the desired sharpening angle and secure it. Using C-Clamps, attach a suitable wood scrap to the table. See Figure 22. This acts as an auxiliary table to support the workpiece.

  • Page 22: Maintenance

    Poor belt tensioning ⁄ tracking. Table The working table and other non-painted sur- faces on the Model G1013 should be protected against rust and pitting. Wiping the sander clean after every use ensures that sawdust is not allowed to trap moisture against bare metal sur- faces.

  • Page 23: Maintenance Notes

    Maintenance Notes Date Approximate Hours Of Use Maintenance Performed G1013 Combination Sander -21-...

  • Page 24: Closure

    Washington location using the address in Section 3: Introduction. The specifications, drawings, and photographs illustrated in this manual represent the Model G1013 as supplied when the manual was prepared. However, due to Grizzly’s policy of continuous improvement, changes may be made at any time with no obligation on the part of Grizzly.

  • Page 25: Machine Data

    Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G1013 COMBINATION SANDER Design Type... Bench Model Overall Dimensions: Base ...10" x 18" Height ...21" Width ...15" Length ...24" Table (Disc) ...5" x 12 Table (Belt)...
  • Page 27 35 PSW05 SWITCH W⁄ MOUNTING NUT PCB01 CARRIAGE BOLT 37 P1013037 RUBBER FOOT 38 PB31 HEX BOLT 39 P1013039 BASE G1013 Combination Sander PARTS LIST 40 P1013040 41 PSS03 42 P1013042 ⁄ -20 X 1" 43 P1013043 44 PB07 45 P1013045...

  • Page 28: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
