G1014Z Main Parts List - Grizzly G1014Z Owner's Manual

REF PART # DESCRIPTION
1 P1014Z001 DUST COVER
2 P1014Z002 EXT RETAINING RING 12MM
3 P1014Z003 BALL BEARING 6201-2RS
4 P1014Z004 DRIVER ROLLER SHAFT
5 P1014Z005 SANDING BELT 6'' X 48''
6 P1014Z006 KEY 5 X 5 X 55
7 P1014Z007 EXT RETAINING RING 15MM
8 P1014Z008 SANDING BELT FRAME
9 P1014Z009 BACK STOP
10 P1014Z010 SET SCREW 5/16-18 X 3/8
11 P1014Z011 DRIVE ROLLER
12 P1014Z012 HEX NUT 5/16-18
13 P1014Z013 FLAT WASHER 5/16
14 P1014Z014 KNOB 5/16-18
15 P1014Z015 BALL BEARING 6202-2RS W/SNAP RING
16A P1014Z016A COMPLETE MITER GAUGE ASSY
17 P1014Z017 BUSHING 15 X 19.4 X 12MM
18 P1014Z018 CARRIAGE BOLT 5/16-18 X 1-1/2
19 P1014Z019 PULLEY COVER V2.07.00
20 P1014Z020 MITER BAR
21 P1014Z021 CAST IRON DISC V2.02.97
22 P1014Z022 SANDING DISC PAPER 9"
23 P1014Z023 TABLE
24 P1014Z024 TRUNNION
25 P1014Z025 FLAT WASHER 1/4
26 P1014Z026 PHLP HD SCR 1/4-20 X 1/2
27 P1014Z027 PHLP HD SCR 10-24 X 3/8
27A P1014Z027A FLANGE SCREW 10-24 X 3/8
28 P1014Z028 POINTER
29 P1014Z029 TABLE SUPPORT BRACKET V2.01.98
30 P1014Z030 SUPPORT BAR
32 P1014Z032 HEX BOLT 5/16-18 X 1/2
33 P1014Z033 TABLE MOUNT
34 P1014Z034 V-BELT M-24 3L240
35 P1014Z035 PULLEY
36 P1014Z036 MOTOR PULLEY
37 P1014Z037 KNOB 10-24
39 P1014Z039 HEX BOLT 5/16-18 X 1
40 P1014Z040 BRACKET
41 P1014Z041 HEX BOLT 5/16-18 X 1
42 P1014Z042 SET SCREW 5/16-18 X 3/8
43 P1014Z043 MOTOR 3/4 HP 110V/220V 1-PH
43-1 P1014Z043-1 CENTRIFUGAL SWITCH
43-2 P1014Z043-2 MOTOR FAN
43-3 P1014Z043-3 MOTOR FAN COVER
43-4 P1014Z043-4 S CAP 200M 125V 1-3/8 x 2-1/4
43-5 P1014Z043-5 S CAPACITOR COVER
43-6 P1014Z043-6 JUNCTION BOX COVER
44 P1014Z044 LOCK KNOB 1/4-20 X 5/8
45 P1014Z045 PLASTIC WASHER 1/4-16
46 P1014Z046 FLAT WASHER #10
49 P1014Z049 STRAIN RELIEF
-56-

G1014Z Main Parts List

REF PART # DESCRIPTION
50 P1014Z050 SWITCH PLATE
51 P1014Z051 HEX NUT 10-24
52 P1014Z052 BASE
53A P1014Z053A GRIZZLY SAFETY PADDLE SWITCH
56 P1014Z056 HEX NUT 5/8-11
57 P1014Z057 HEX BOLT 5/8-11 X 9
59 P1014Z059 IDLER SHAFT V3.08.97
62B P1014Z062B ROLLER ADJUST BAR
64 P1014Z064 IDLER ROLLER V3.08.97
69 P1014Z069 MITER BODY
70 P1014Z070 TILT SCALE
71 P1014Z071 POWER CORD
77 P1014Z077 HEX WRENCH 4MM
80 P1014Z080 KEY 5 X 5 X 40
81A P1014Z081A ROCKER PLATE
82A P1014Z082A SHORT LEVER
83A P1014Z083A ROCKER ARM
84A P1014Z084A ECCENTRIC
85A P1014Z085A LONG LEVER
86A P1014Z086A KNOB 3/8-16
87A P1014Z087A SPACER
88A P1014Z088A HEX BOLT 3/8-16 X 3/4
89 P1014Z089 CAP SCREW 10-24 X 5/8
90 P1014Z090 MOTOR CORD 16AWG x 3C
91 P1014Z091 HEX BOLT 3/8-16 X 1-1/2
92 P1014Z092 FLAT WASHER 3/8
93 P1014Z093 WASHER PLATE 19 X 88
94A P1014Z094A KNOB 3/8-24
95 P1014Z095 LOCK WASHER 5/16
96 P1014Z096 SET SCREW 5/16-18 X 3/4
97 P1014Z097 FENDER WASHER 5/16 X 21 X 2
98 P1014Z098 HEX NUT 3/8-16
99 P1014Z099 GRAPHITE PAD 6W X 17L
100 P1014Z100 DUST PORT
101 P1014Z101 FENDER WASHER 3/8
102 P1014Z102 BELT DIRECTION ARROW
103 P1014Z103 TABLE TILT POINTER
105 P1014Z105 HEX NUT 3/8-16
106 P1014Z106 LOCK WASHER 5MM
107 P1014Z107 HEX BOLT 1/4-20 X 1/2
108 P1014Z108 FLAT WASHER 1/4
114A P1014Z114A IDLER ROLLER GUARD V2.03.08
114A-1 P1014Z114A-1 SLEEVE GUARD
115 P1014Z115 LOCK KNOB 1/4-20
116 P1014Z116 FLAT WASHER 1/4
117 P1014Z117 FLAT WASHER 5/16
118 P1014Z118 PHLP HD SCR 10-24 X 3/8
119 P1014Z119 DUST PORT (ABS) 2-1/2"
120 P1014Z120 MOTOR LABEL
126 P1014Z126 LOCK KNOB 10-32
127 P1014Z127 FLAT WASHER #10
Model G1014Z/G1014ZX (Mfd. Since 07/17)
