Grizzly G1014Z Owner's Manual page 6

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G1014Z COMBINATION SANDER 6" X 48" BELT 9"
Product Dimensions:
Weight.............................................................................................................................................................. 117 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................................... 30 x 24 x 56 in.
Footprint (Length x Width)............................................................................................................................ 23 x 19 in.
Shipping Dimensions:
Type..................................................................................................................................................... Cardboard Box
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 122 lbs.
Length x Width x Height....................................................................................................................... 19 x 29 x 15 in.
Must Ship Upright.................................................................................................................................................... No
Electrical:
Power Requirement............................................................................................. 110V or 220V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 110V
Full-Load Current Rating....................................................................................................... 12A at 110V, 6A at 220V
Minimum Circuit Size.......................................................................................................... 15A at 110V, 15A at 220V
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 16 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................. 5-15 for 110V
Recommended Plug Type...................................................................................................................... 6-15 for 220V
Switch Type.................................................................................................. Paddle Safety Switch w/Removable Key
Motors:
Main
Horsepower............................................................................................................................................. 3/4 HP
Phase............................................................................................................................................ Single-Phase
Amps....................................................................................................................................................... 12A/6A
Speed................................................................................................................................................ 3450 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer .................................................................................................................................. Belt Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Main Specifications:
Belt Sander Info
Sanding Belt Width...................................................................................................................................... 6 in.
Sanding Belt Length.................................................................................................................................. 48 in.
Sanding Belt Speed........................................................................................................................... 2300 FPM
Sanding Belt Tilt..................................................................................................................................... 90 deg.
Max Height of Belt in Vertical Position....................................................................................................... 56 in.
Belt Tension Release Type......................................................................................................... Quick Release
Platen Type.............................................................................................................................. Graphite Coated
Platen Length............................................................................................................................................. 17 in.
Platen Width.......................................................................................................................................... 6-1/4 in.
The information contained herein is deemed accurate as of 10/19/2017 and represents our most recent product specifications.
Model G1014Z
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
-4-
MACHINE DATA
DISC Z SERIES
Model G1014Z/G1014ZX (Mfd. Since 07/17)
SHEET
PAGE 1 OF 2
