Figure 4: Connecting the VS-3232DN
5.1
Port Numbering
All cards (except DVI dual link cards) have four physical ports. Numbering of ports
is sequential from top to bottom and left to right. Each DVI dual link card provides
two physical ports which causes the loss of two numbers in the numbering
sequence of that card only. A sample numbering is shown in
Figure
5.
14
VS-3232DN - Connecting the VS-3232DN
