Defining The Vs-3232Dn 4X4 To 32X32 Modular Multi-Format Digital Matrix Switcher; Figure 1: Vs-3232Dn Front Panel - Kramer VS-3232DN User Manual

The VS-3232DN is housed in a 19" rack-mountable enclosure.
3.1 Defining the VS-3232DN 4x4 to 32x32 Modular Multi-
Format Digital Matrix Switcher
This section defines the front and rear panels of the VS-3232DN.

Figure 1: VS-3232DN Front Panel

8
The VS-3232DN is a sophisticated device but has nevertheless been
designed to be simple to operate using an intuitive front panel keypad. For
details of how to route inputs to outputs, see
Buttons 14, 15 and 16 function as the TAKE, MENU and LOCK buttons
respectively.
Section 6.4.
VS-3232DN – Overview
