17.3.2
System Commands
Command
CPEDID
GEDID
GEDID-EXT
HDCP-MOD
HDCP-STAT
LDEDID
LOCK-FP
MODULE-TYPE
MODULE-VER
P2000
17.3.2.1
CPEDID
Functions
CPEDID
Set
Get
-
Description
Copy EDID data from the
Set
output to the input EEPROM
Get
-
Response
~nn@CPEDIDSPoutput_id,input_idCR LF
Parameters
output_id – video output ID: 1-32 (varies according to installed output cards, see
input_id – video input ID: 1-32 (varies according to installed input cards, see
Response Trigger
Response is sent to the com port from which the Set was received (before execution)
Notes
K-Config Example
Copy the EDID data from output 8 to input 1:
"#CPEDID 8,1,0x1",0x0D
112
Description
Copy EDID data from the output to the input EEPROM
Read EDID data
Read EDID data from external device connected to output
Set/Get HDCP mode
Get HDCP signal status
Load EDID data
Lock front panel
Set/Get module type, slot location, and status
Read module firmware version
Switch to protocol 2000
Permission
End User
-
Syntax
#CPEDIDSPoutput_id,input_idCR
-
Transparency
Public
-
Section
5.1)
Section
5.1)
VS-3232DN - Protocol 3000
