15

Technical Specifications

15.1

VS-3232DN Chassis

BANDWIDTH:
CONTROLS:
POWER CONSUMPTION:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
COOLING:
ENCLOSURE TYPE:
RACK MOUNT:
DIMENSIONS:
SHIPPING DIMENSIONS:
PRODUCT WEIGHT:
SHIPPING WEIGHT:
VIBRATION:
SAFETY REGULATORY
COMPLIANCE:
ENVIRONMENTAL
REGULATORY COMPLIANCE:
INCLUDED ACCESSORIES:
Specifications are subject to change without notice at
15.2

Quick VS-3232DN Card Comparison

Card Ports
HDBT 4 HDBaseT TP on RJ45
connectors
4 RS-232 Serial and 4 IR on
10-pin terminal blocks
1 Ethernet on an RJ-45 connector
H 4 HDMI
HAD 4 HDMI
4 Digital audio on RCA connectors
HAA 4 HDMI
4 Analog audio on 3.5mm mini
jacks
HDCP 4 DVI-D on a DVI Molex 24-pin (F)
connector
DGKat 4 TP DGKat on RJ-45
4 Serial on 3-pin terminal blocks
82
Supports up to 3.4Gbps bandwidth per channel (limited by the
card installed)
Front panel buttons, Infrared remote control transmitter, RS-232,
Ethernet
100-240V AC, 50/60Hz, 300VA
0° to +55°C (32° to 131°F)
–45° to +72°C (–49° to 162°F)
10% to 90%, RHL non-condensing
Forced air, fan
Aluminum
With supplied rack ears
19" x 14.2" x 6U (48.3cm x 36cm x 26.6cm W, D, H)
60cm x 49.3cm x 39cm
13.54kg (29.85lbs) approx.
14.9kg (32.85lbs) approx.
ISTA 1A in carton (International Safe Transit Association)
CE, UL, FCC
Complies with appropriate requirements of RoHs and WEEE
Power cord, Infrared remote control transmitter
www.kramerav.com
BW per
Channel
Vid: 2.25Gbps
Serial:
115200
2.25Gbps
2.25Gbps
2.25Gbps
2.25Gbps
Vid: 1.65Gbps
Serial: 19200
Max. Range Compliance
130m (430ft) HDCP 1.4,
normal mode HDMI 1.3a,
HDBaseT
180m (590ft)
ultra-mode
(1080p@60Hz
@24bpp)*
15m (49ft) HDCP 1.4,
HDMI 1.3a
15m (49ft) HDCP 1.4,
HDMI 1.3a
15m (49ft) HDCP 1.4,
HDMI 1.3a
15m (49ft) HDCP, HDMI
90m (300ft) – HDCP 1.4,
1080p @60Hz* HDMI 1.3a
VS-3232DN - Technical Specifications
3D
Pass
Thru
Yes
Yes
Yes
Yes
Yes
Yes
