Kramer VS-3232DN User Manual page 79

10.13.1 AAD-IN4-F32 / AAD-OUT4-F32 Configuration
The AAD-IN4-F32 configuration table appears as follows:
AAD-IN4-F32 Input Card
Parameter
Pattern
Reset Input
Audio Select
Audio Mute
Volume
Audio Balance
Audio Bass
Audio Treble
The AAD-OUT4-F32 configuration table appears as follows:
AAD-OUT4-F32 Output Card
Parameter
Reset Output
Volume
Audio Balance
Audio Bass
72
When a multi-channel audio input signal is routed to a card with
digital and analog stereo audio outputs, the digital connectors output
multi-channel audio and the analog connectors output the front right
and front left audio channels only.
Description
RGB Bar, Black.
Re-power—Power cycles the port.
Factory Default—Performs a factory reset of the port to default
values.
Selects the audio source:
Auto—Audio signal selection is controlled by the presence or
absence of a plug in the RCA port. When present, AUD-Digital is
selected, when absent, AUD-Analog is selected.
AUD-Digital—Digital audio is selected from the RCA ports.
AUD-Analog—Analog audio from the 5-pin terminal blocks is
selected.
MUTE—Mutes the audio input.
Non-MUTE—Unmutes the audio input.
Note: When set to Mute, any change to the audio parameters
automatically sets this to unmute.
Note: Not applicable when digital audio is selected.
Sets the audio output volume (0–70).
Note: Not applicable when digital audio is selected. Applies to analog
inputs and outputs only.
Sets the audio output channel balance (0–100).
Note: Not applicable when digital audio is selected.
Sets the audio output bass level (0–15).
Note: Not applicable when digital audio is selected.
Sets the audio output treble level (0–15).
Note: Not applicable when digital audio is selected.
Description
Re-power—Power cycles the port.
Factory Default—Performs a factory reset of the port to default
values.
Sets the audio output volume (0–70).
Note: Not applicable when digital audio is selected.
Sets the audio output channel balance (0–100).
Note: Not applicable when digital audio is selected.
Sets the audio output bass level (0–15).
Note: Not applicable when digital audio is selected.
VS-3232DN - Using the Input / Output Cards
Default
RGB Bar
-
Auto
Non-MUTE
50
50
7
7
Default
-
50
50
7
