Kramer VS-3232DN User Manual page 16

# Feature
1
2
3
4
Double-
5
function Menu
Selector Button
6
Buttons Functions
Area
7
8
9 BREAKAWAY Button
10 DEFAULT SETUP Button
11 OUTPUTS/INPUTS
LCD Display
12 IR Receiver
13 IR LED
14 TAKE Button
15 MENU Button
16 LOCK Button
17 Power Supply
18
19 POWER LED
20 ERROR LED
VS-3232DN – Overview
Function
ESC Press to exit the current operation
EDID Press to assign EDID channels
STO Press to store the current setup in a preset. After pressing the
MENU button, this button lights and is enabled.
ALL Press to connect an input to all outputs. After pressing the
MENU button, this button lights and is enabled.
OFF Press to turn off an output. After pressing the MENU button, this
button lights and is enabled.
Press to recall a preset. After pressing the MENU button, this
RCL
button lights and is enabled.
Press to set the delay between confirming an action and the
DELAY
execution of the action
ENT Press to complete the input-output setup when using a one-digit
number instead of two digits. For example, to enter input 5, you
can press either 05 or 5, ENT.
Press to enter the options in a setup menu.
Press to exit a menu (see
Press to recall the default setup (see
Displays the outputs (upper row) switched to the selected inputs
(lower row), (see
Displays user interface messages and menus.
Infrared remote control sensor
Lights yellow when receiving commands from the IR remote
control transmitter
Press to confirm actions (see
Press once to enable the ALL, OFF, STO and RCL buttons (see
Section 7).
Press again to enter the configuration menu (see
When in a Menu, press to cycle through the menu items.
Press and hold for approximately 2 sec to lock/unlock the front
panel buttons (see
Supplies power to the device.
Lights green when power supply is active and the device is
powered on.
Lights red when an error is detected. Briefly lights red
immediately following a power disruption (e.g., cable
disconnection, power off, and so on).
Section 7)
Section
Section 6.1).
Section 6.3.2)
Section 6.5)
6.4.5)
Section 7.2).
