16

Default Settings

16.1

Default Communication Parameters

EDID
EDID data is passed between Output 1 and Input 1
RS-232
Protocol 2000/3000
Baud Rate:
Data Bits:
Stop Bits:
Parity:
Command Format:
P2000, to switch Input 4 to Output 2:
P3000, to switch Input 4 to Output 2:
Ethernet
IP Address:
TCP Port #:
Concurrent TCP Connections:
16.2

Factory Default EDID

16.2.1 HDBT-IN4-F32 / HDBT-OUT4-F32
Monitor
Model name............... VS-32HDBST
Manufacturer............. KRM
Plug and Play ID......... KRM0200
Serial number............ 1
Manufacture date......... 2006, ISO week 12
Filter driver............ None
-------------------------
EDID revision............ 1.3
Input signal type........ Digital (DVI)
Color bit depth.......... Undefined
Display type............. RGB color
Screen size.............. 700 x 390 mm (31.5 in)
Power management......... Not supported
Extension blocs.......... 1 (CEA-EXT)
-------------------------
DDC/CI................... Not supported
Color characteristics
Default color space...... Non-sRGB
Display gamma............ 2.20
Red chromaticity......... Rx 0.640 - Ry 0.341
Green chromaticity....... Gx 0.286 - Gy 0.610
Blue chromaticity........ Bx 0.146 - By 0.069
White point (default).... Wx 0.284 - Wy 0.293
Additional descriptors... None
Timing characteristics
Horizontal scan range.... 31-94kHz
Vertical scan range...... 50-85Hz
Video bandwidth.......... 170MHz
CVT standard............. Not supported
GTF standard............. Not supported
84
9600
8
1
None
HEX
0x01, 0x84, 0x82, 0x81
#AV 4>2
192.168.1.39
5000
1
VS-3232DN - Default Settings
