Kramer VS-3232DN User Manual page 125

17.3.2.7 LOCK-FP
Functions
LOCK-FP
Set
LOCK-FP?
Get
Description
Lock front panel
Set
Get
Get front panel lock state
Response
Set: ~nn@LOCK-FPSPlock_modeSPOKCR LF
Get: ~nn@LOCK-FPSPlock_modeCR LF
Parameters
lock_mode - 0/OFF (unlocks the front panel buttons), 1/ON (locks the front panel buttons)
Response Trigger
Notes
K-Config Example
Lock the front panel of the VS-3232DN:
"#LOCK-FP 1",0x0D
17.3.2.8 MODULE-TYPE
Functions
MODULE-TYPE
Set
MODULE-TYPE?
Get
Description
Set module type and slot
Set location
Get Get module type and status by
slot location
Response
~nn@MODULE-TYPESPm_id,m_type,statusCR LF
Parameters
m_id – Module ID (slot number): 01-32
m_type – Module type: 0 (DVI), 1 (HDCP), 03 (HDMI), 4 (DL), 06 (HS), 07 (DP), 08 (SDI), 09 (F610),
10 (F670), 12 (DGKat), 16 (VGA), 18 (VGAA), 22 (AAD), 24 (HAA), 25 (HAD), 28 (DPI), 30 (HDBT),
32 (SDIA), 33 (SDID), 34 (HDBT7), 35 (DGKatA), 41 (UHD), 42 (UHDA), 45 (HDBTA)
status – Module status: 0 (OK), 1 (unknown error), 2 (no communication), 3 (module missing)
Response Trigger
Notes
K-Config Example
Set the card (module) installed in slot 4 to HDBT:
"#MODULE-TYPE 04,30",0x0D
118
Permission
End User
End User
Syntax
#LOCK-FPSPlock_modeCR
#LOCK-FP?CR
Permission
Admin
End User
Syntax
#MODULE-TYPESPm_id,m_typeCR
#MODULE-TYPE?SPm_idCR
Transparency
Public
Public
Transparency
Public
Public
VS-3232DN - Protocol 3000
