10.11 Defining the SDIA-IN4-F32

The SDIA-IN4-F32 is a 4-Input SDI with Analog Audio Card (F-32):
10.11.1 SDIA-IN4-F32 Configuration
The SDIA-IN4-F32 configuration table appears as follows:
SDIA-IN4-F32 Input Card
Parameter
Color Space
Reset Input
Volume
Audio Balance
Audio Bass
Audio Treble
Audio Mute
Audio Select
SDI_AUDIO_
SWITCH
10.11.2 SDI Audio Switch Configuration
The selected in-band SDI channels to be embedded into the HDMI matrix port
audio channel can be configured in the SDI_AUDIO_SWITCH menu. Each input's
66
Description
Selects the color space of the internal video bus (input is converted
to this color space for internal processing only): RGB, YUV422,
YUV444.
Re-power—Power cycles the port.
Factory default—Performs a factory reset to default values of the
port.
Sets the volume of audio port. Range: 0-70.
Note: Not applicable when digital audio is selected.
Sets the balance of the audio port. Range: 0-100.
Note: Not applicable when digital audio is selected.
Sets the bass of the audio port. Range: 0-15.
Note: Not applicable when digital audio is selected.
Sets the treble of the audio port. Range: 0-15.
Note: Not applicable when digital audio is selected.
Enables muting or enabling the audio on the audio port:
MUTE—Mutes the audio input.
Non-MUTE—Unmutes the audio input.
Note: When set to Mute, any change to the audio parameters
automatically sets this to unmute.
Note: Not applicable when digital audio is selected.
Selects the audio source:
Auto—Audio signal selection is controlled by the presence or
absence of a plug in the 3.5mm mini jack. When present, AUD-
Analog is selected, when absent, AUD-Embedded is selected.
AUD-Embedded—In-band SDI audio is selected.
AUD-Analog—3.5mm mini jack analog stereo audio is selected.
Selects the SDI audio channel. Range: 0-15 (see
Only available when Audio Select is set to AUD-Embedded.
Section 10.11.2).
VS-3232DN - Using the Input / Output Cards
Default
RGB
-
50
50
7
7
Non-MUTE
Auto
0
