Kramer VS-3232DN User Manual page 77

VGAA-IN4-F32 Input Card
Parameter
Vertical-Active
Save Timing Para
Recall Timing Para
Volume
Audio Balance
Audio Bass
Audio Treble
Audio Mute
R-offset
G-offset
B-offset
R-gain
G-gain
B-gain
The VGAA-OUT4-F32 configuration table appears as follows:
VGAA-OUT4-F32 Output Card
Parameter
Reset Output
Switch Speed
Volume
Audio Balance
Audio Bass
Audio Treble
Audio Mute
OUT_HSYNC_
INVERT
70
Description
Set the value for vertical active pixels.
(1–3000)
(0–31)
(0–31)
Sets the audio output volume (0–70).
Sets the audio output channel balance (0–100).
Sets the audio output bass level (0–15).
Sets the audio output treble level (0–15).
MUTE—Mutes the audio input.
Non-MUTE—Unmutes the audio input.
Note: When set to Mute, any change to the audio parameters
automatically sets this to unmute.
(0–63)
(0–63)
(0–63)
(0–63)
(0–63)
(0–63)
The Auto Adjust feature requires the device to recalculate the
parameters based on the currently connected source. The result may
be different from the standard parameters for the currently set
resolution. The result is saved in non-volatile memory and is recalled
when the same source is used again. In order to revert to auto
predefined parameters, either reset to factory setting with the
relevant source connected or connect a different source.
Description
Re-power: power cycles the port.
Factory: performs a factory reset of the port to default values.
When switching between different sources the switching time can be
reduced by setting the fast switch level (Ex-fast Switch, Fast Switch
or Normal Switch).
Sets the audio output volume (0–70).
Sets the audio output channel balance (0–100).
Sets the audio output bass level (0–15).
Sets the audio output treble level (0–15).
MUTE: mutes the audio input.
Non-MUTE: unmutes the audio input.
Note: When set to Mute, any change to the audio parameters
automatically sets this to unmute.
Sets the H_SYNC invert.
(0, 1)
VS-3232DN - Using the Input / Output Cards
Default
As detected
N/A
N/A
50
50
7
7
Non-MUTE
32
32
32
32
32
32
Default
-
Normal
Switch
50
50
7
7
Non-MUTE
0
