Measurement Specifications; Environmental Specifications - RayTek GP Series Operating Instructions Manual

5.3.2 Measurement Specifications

Temperature range:
Spectral response:
Accuracy:
(with GP monitor)
Repeatability:
Response Time:
Temperature Coefficient: 0.15°C per °C (0.15°F per °F)

5.3.3 Environmental Specifications

Dimensions:
Weight:
Environmental Rating:
Ambient Operating:
Head:
with air cooling:
with water cooling:
Storage temperature:
Relative Humidity:
Vibration:
GP Series
GPR/GPS Sensing Head
-18 to 538°C
8 to 14 µm
±1% of reading or ±1°C (2°F),
whichever is greater
at 23°C ± 5°C (73 ± 9°F) ambient
±0,5% of reading or ±1°C (2°F),
whichever is greater
at 23°C ± 5°C (73 ± 9°F) ambient
300 ms (95% response, 4/20mA output)
see sections 5.1 and 5.2, page 44 f.
GPR: 275 g (9.7 oz), GPS: 290 g (10 oz)
NEMA-4 (IEC 529, IP 65) rated with
conduit adapter and compression fitting
(which prevents liquid from entering
through the connector)
GPR: 0 to 65°C
GPS: 0 to 65°C (laser switch off 50°C/122°F)
0 to 120°C (32 to 248°F)
0 to 177°C (32 to 351°F)
-30 to 65°C (-22 to 149°F)
10-95%, non-condensing
MIL-STD-810D (IEC 68-2-6): 3G's, 11 to
200Hz, any axis
Rev. F 10/2011
55
