The deadband is the temperature/value band (±) about a setpoint,
wherein an alarm output or relay cannot change state.

3.4.5 Analog 4 - 20 mA Output

Note: The 4 - 20 mA analog output is disabled when the
thermocouple output is active, see section 3.4.10
Output, page 32.
Complete the following for setting a temperature to correspond to
the 4-20mA analog output:
1. Press the
the following figure.
Figure 17: 4 mA Analog Output Display
2. Press the
displays.
3. Press the and
4. Pressing the
Figure 18: 20 mA Analog Output Display
5. Press the and
GP Series
button until the 4 mA output display displays, see
button again, and the current 4 mA temperature
buttons to adjust the temperature value.
button again brings up the 20 mA display.
buttons to adjust the temperature value.
Rev. F 10/2011
GP Monitor
Thermocouple
27
