3 GP Monitor

3.1 Technical Data

3.1.1 Measurement Specifications

Input Accuracy:
Output Accuracy:
Response Time:
Display:
Emissivity:
Warm-up Time:
Peak Hold:
Valley Hold:
Averaging:
Fail-Safe:
GP Series
0 – 5 V input resolution: 1 mV,
accuracy: ± 2 mV
4 – 20 mA input resolution: 0.01 mA
accuracy: ± 0.02 mA
J, K, E, N, T thermocouple input:
± 0.5 % or ± 2°C, whichever is greater
R, S thermocouple input:
± 0.5 % or ± 3°C, whichever is greater
4 – 20 mA output resolution: 0.014 mA
accuracy: ± 0.02 mA
J, K, E, N, T thermocouple output:
± 0.5 % or ± 2°C, whichever is greater
R, S thermocouple output:
± 0.5 % or ± 4°C, whichever is greater
300 ms (GPR/GPS system)
200 ms (all other)
4 digit LED
0.10 to 1.09, adjustable in 0.01 increments –
H001 (GP heads) and H007 (XR heads) only
5 s
0 to 998 s (999=infinite hold)
0 to 998 s (999=infinite hold)
0 to 60 s
Full or low scale, depending upon system
failure, see section 6.1
Seite 58.
Rev. F 10/2011
GP Monitor
Fail-Safe Operation,
5
