Figure 3: Mounting Bracket Accessory Installation
2. Insert the Tab on the side of each fixing clamp (one per side) into
the hole on the side of the monitor housing and hold them. You
might need to loosen the fixing clamp screws first, see Figure 4.
Figure 4: Completing the Installation
GP Series
Gasket
Tab
Clamp Scres
Mounting Bracket
Before mounting bracket, connect wires
and attach rear cover
Rev. F 10/2011
GP Monitor
Hole
Fixing Clamp
Tighten Fixing Clamp
Screws
9
