5.2 Zubehör
Accessories include items that may be ordered at any time and added
on-site:

Adjustable Mounting Bracket

Air Purge Collar

90° Umlenkspiegel (XXXTXXACRA)
Visierhilfe (nur GPR) (XXXTXXACSV)
Schutzrohradapter (XXXTXXACCA)
Rohradapter (XXXTXXACPA)
Starrer Montagewinkel (im Lieferumfang) (XXXTXXACFB)
Montagemutter, (im Lieferumfang) (XXXTXXACMN)
Kabel: 4 m
Hochtemperaturkabel: 8 m oder 15 m
5.2.1 Adjustable Mounting Bracket
An adjustable mounting bracket is available if you require a sensor
that can be aimed at different targets from the same mounted
position.
Figure 37: Adjustable Mounting Bracket
5.2.2 Air Purge Collar
The Air Purge Collar is used to keep dust, moisture, airborne
particles, and vapors away from the lens. It can be installed before or
after the mounting bracket. It must be screwed in fully. Air flows into
GP Series
GPR/GPS Sensing Head
(XXXTXXACAB)
(XXXTXXACAP)
Rev. F 10/2011
49
