When the decimal is On, it will be positioned at a tenth of a degree
(for example, 888.8). Press the button
temperature display
H003
The sensor attached as H003 has a fixed emissivity and no additional
monitor adjustments are necessary.
H004/H005/H007
If H004, H005, or H007 are displayed, press the
the decimal Off or to set the location of the decimal on the display.
Use the following as a guide:
d = 0 Decimal turned off
d = 1 Decimal located at ones position (for example 8888.)
d = 2 Decimal located at tens position (for example 888.8)
d = 3 Decimal located at hundreds position (for example 88.88)
d = 4 Decimal located at thousands position (for example 8.888)
Both H004 and H005 have additional settings as follows:
For H004, press the
equivalent temperature value (using the
once more to adjust the 5 V equivalent temperature value.
H005/H007
For H005/H007, press the
4 mA equivalent temperature value (using the
Press
once more to adjust the 20 mA equivalent temperature value.
H006
For H006, press the
("0") or On ("1"). A "d" is displayed on the monitor. When the
decimal is On, it will be positioned at a tenth of a degree (e.g., 888.8).
Press the
button again to be able to select the thermocouple input
type. Use the following as a guide:
TC1 = J-type thermocouple input
GP Series
.
button again to be able to adjust the 0 V
button again to be able to adjust the
button once to be able to turn the decimal Off
Rev. F 10/2011
GP Monitor
again to return to the
button once to turn
and
arrows). Press
and
arrows).
21
