GP Monitor

3. Press the

temperature or value (Setpoint value). Use the

to adjust the alarm value.

4. Press the

figure appears. If you see a number "1," it means the Normally

Low setpoint will change state when the target temperature or

value exceeds the alarm value. If a number "0" displays, the

Normally Low setpoint will change state when the target

temperature or value is lower than the setpoint alarm value.

If you see a number "3," it means the Normally High setpoint will

change state when the target temperature or value exceeds the alarm

value. If a number "2" displays, the Normally High setpoint will

change state when the target temperature or value is lower than the

setpoint alarm value.

Figure 14: Setpoint Alarm (Trigger) Display

Note that the "O" and "L" indicators on the monitor are controlled

by SP1 and SP2. The "L" lights when the input signal has fallen

below either the SP1 or SP2 value and when the trigger level ("b") is

set to either "0" or "2". The "O" indicator lights when the input

signal has risen above either the SP1 or SP2 value and when the

trigger level ("b") is set to either "1" or "3". The following figures

shows examples of how the setpoints change state when triggered.

button, and the display shows the current alarm

button again and a display similar to the following

Rev. F 10/2011

and

arrows

GP Series
