Rating:
Operating Temperature: 0 to 50°C (32 to 122°F)
Relative Humidity:
Storage Temperature:

3.2 Mounting Instructions

The GP monitor meets NEMA-12 (IEC529, IP54) requirements (front
panel only) for protection of the electronics when mounted properly.
It should be surface mounted using the flanges and holes provided
and mounted in such a manner to allow the free flow of air around
the unit. Ambient temperatures should be kept within the range of
0 to 50°C (32 to 120°F).
Mount the monitor as far away as possible from potential
sources of electromagnetic interference!
Complete the following steps to mount the GP monitor to a panel, see
also Figure 2:
1. Cut a hole 45 mm high by 92 mm wide (1.8 in by 3.62 in) in the
panel.
2. Slip the gasket over the rear of the monitor and then back the
monitor into the hole from the front side of the panel. (Mounting
bracket and cosmetic frame are available as accessories.)
3. Attach the fixing clamps to both sides of the monitor. Make sure
the tab is secure in the hole on both sides.
4. Fix the monitor with the clamp screws!
GP Series
IP 54 (NEMA-12), front panel only
10 - 95 %, non-condensing
-30 to 65°C (-22 to 150°F)
Rev. F 10/2011
GP Monitor
7
