The unit be used in a closed cabinet to prevent electrical
shock!

3.3.7 Output Connections

The monitor has the following outputs:
4 - 20 mA
Thermocouple outputs (J, K, E, N, T, R, and S)
Setpoints 1 und 2, optional: potential free relay contacts
4 - 20 mA
Pin Function
1 4-20 mA output
2 Analog ground
8 Shield
GP Series
Pin Funktion
18 Erde (Netz)
19 N Nullleiter
20 H Phase
Table 7: Power Connections
Rev. F 10/2011
Thermocouple
Pin Function
2 Thermocouple (-)
3 Thermocouple (+)
GP Monitor
17
