2. Press the and
to the appropriate emissivity.
3. Press the button until the temperature displays.

3.4.4 Setpoints 1 and 2

Setpoints are preset at the factory for the highest measurement value
but are deactivated by default. To adjust setpoints, complete the
following:
1. In temperature/value display, press the
similar to the following figure appears. Setpoint 1 shows as "S1"
followed by a number 0, showing that Setpoint 1 is Inactive, or a
number 1, designating active.
Figure 13: Setpoint Display (Showing Setpoint 1 Active)
2. When either S1 or S2 is displayed, press the
activate or deactivate the setpoint (a number "1" displays when
the setpoint is active, a number "0" displays when it's inactive).
GP Series
Figure 12: Emissivity Display
buttons to change the number on the display
Rev. F 10/2011
GP Monitor
button until a display
or buttons to
