Platform Control Indicator Panel - JLG 340AJ Operation And Safety Manual

Platform Control Indicator Panel

(See Figure 3-5., Platform Control Indicator Panel)
NOTE: The indicator lights will illuminate for approximately 1 second
when the key is positioned to the on position to act as a self test.
1. AC Generator (If Equipped)
Indicates the generator is in operation.
2. Platform Overload Indicator (If Equipped)
Indicates the platform has been overloaded.
3121258
SECTION 3 - MACHINE CONTROLS AND INDICATORS
3. Tilt Alarm Warning Light and Alarm
This red illuminator indicates that the chassis is on a slope.
An alarm will also sound when the chassis is on a slope and
the boom is out of transport position. If lit when boom is out
of transport position, lower to below horizontal then reposi-
tion machine so that it is level before continuing operation.
If the boom is above horizontal and the machine is on a
slope, the tilt alarm warning light will illuminate and an
alarm will sound and CREEP is automatically activated.
IF TILT WARNING LIGHT IS ILLUMINATED WHEN BOOM IS RAISED OR EXTENDED,
RETRACT AND LOWER TO BELOW HORIZONTAL THEN REPOSITION MACHINE SO THAT
IT IS LEVEL BEFORE EXTENDING BOOM OR RAISING BOOM ABOVE HORIZONTAL.
– JLG Lift –
Tilt Angle Market
3° CE & Australia
5° ANSI, CSA & Japan
