Operation and Safety Manual
Original Instructions, keep this manual with the machine at all times.
Model
3394RT
4394RT
S/N-0200239053
to Present
P/N - 3121641
ANSI
March 2, 2016
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4394RT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for JLG 4394RT

  • Page 1 Operation and Safety Manual Original Instructions, keep this manual with the machine at all times. Model 3394RT 4394RT S/N-0200239053 to Present P/N - 3121641 ANSI March 2, 2016 ®...
  • Page 3 The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating procedures essential for the safe and proper machine operation for its intended purpose. Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior notification. Contact JLG Industries, Inc. for updated information.
  • Page 4 INDICATES INFORMATION OR A COMPANY POLICY THAT RELATES DIRECTLY INDICATES A POTENTIALITY HAZARDOUS SITUATION. IF NOT AVOIDED, OR INDIRECTLY TO THE SAFETY OF PERSONNEL OR PROTECTION OF PROP- COULD RESULT IN SERIOUS INJURY OR DEATH. THIS DECAL WILL HAVE AN ERTY. ORANGE BACKGROUND. – JLG Lift – 3121641...
  • Page 5 Product Modifications JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER Product Safety OF RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT THE CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE. Contact: Product Safety and Reliability Department NOTICE JLG Industries, Inc.
  • Page 6 Manual Revised ......March 2, 2016 – JLG Lift – 3121641...
  • Page 7: Table Of Contents

    3.6 ENGINE OPERATION ......3-14 2.2 PREPARATION, INSPECTION, AND Platform/Ground Select Switch....3-14 3121641 – JLG Lift –...
  • Page 8 Tires ......... 5-4 – JLG Lift –...
  • Page 9 Lifting and Tie Down Chart (Sheet 2 of 2) ..3-25 5-1. Engine Operating Temperature Specifications - Deutz - Sheet 1 of 2 ... . .5-8 3121641 – JLG Lift –...
  • Page 10 5-13 Decal Legend - CE/AUS ......5-33 Inspection and Repair Log ..... . 6-1 – JLG Lift – 3121641...
  • Page 11: Section 1 - Safety Precautions

    JLG Industries, Inc. (“JLG”). A maintenance program, using the information provided in this manual and the Service and Maintenance Manual,...
  • Page 12: Pre-Operation

    JLG Industries, Inc. • Read, understand, and obey all applicable employer, local, and governmental regulations as they pertain to your utili- zation and application of the machine.
  • Page 13: Machine Inspection

    JLG. • Check the machine for modifications to original compo- • Ensure that the ground conditions are adequate to support nents.
  • Page 14 • When two or more persons are in the platform, the operator shall be responsible for all machine operations. • Always ensure that power tools are properly stowed and never left hanging by their cord from the platform work area. – JLG Lift – 3121641...
  • Page 15: Trip And Fall Hazards

    • Prior to operation, ensure all gates and rails are fastened and secured in their proper position. • JLG Industries, Inc. recommends that all persons in the plat- form wear a full body harness with a lanyard attached to an authorized lanyard anchorage point while operating this machine.
  • Page 16: Electrocution Hazards

    50,000 volts. One foot additional clearance is required for every additional 30,000 volts or less. – JLG Lift – 3121641...
  • Page 17: Tipping Hazards

    • Never exceed the maximum work load as specified on the Over 750 KV to 1000 KV 45 (14) platform. Keep all loads within the confines of the platform, unless authorized by JLG. NOTE: This requirement shall apply except where employer, local or govern- mental regulations are more stringent.
  • Page 18: Beaufort Scale (For Reference Only)

    32-38 13.9-17.1 Near Gale/Moderate Gale Whole trees in motion. Effort needed to walk against the wind. 39-46 17.2-20.7 Fresh Gale Twigs broken from trees. Cars veer on road. 47-54 20.8-24.4 Strong Gale Light structure damage. – JLG Lift – 3121641...
  • Page 19: Crushing And Collision Hazards

    • Keep hands and limbs out of the scissor arm assembly dur- ing operation and when elevated without safety prop engaged. • Watch for obstructions around machine and overhead when driving. Check clearances above, on sides, and bot- tom of platform when lifting or lowering platform. 3121641 – JLG Lift –...
  • Page 20 • Keep non-operating personnel at least 6 ft. (1.8m) away from machine during all operations. • Under all travel conditions, the operator must limit travel speed according to conditions of ground surface, conges- tion, visibility, slope, location of personnel, and other fac- tors. 1-10 – JLG Lift – 3121641...
  • Page 21: Towing, Lifting, And Hauling

    • Ensure replacement parts or components are identical or damage to the machine or property. A maintenance program equivalent to original parts or components. 3121641 – JLG Lift – 1-11...
  • Page 22: Battery Hazards

    CLEAN WATER AND SEEK MEDICAL ATTENTION. • Charge batteries only in a well ventilated area. • Avoid overfilling the battery fluid level. Add distilled water to batteries only after the batteries are fully charged. 1-12 – JLG Lift – 3121641...
  • Page 23: Section 2. User Responsibilities, Machine Preparation And Inspection

    4. Use of approved fall protection device. the machine or the job site. 5. Enough knowledge of the mechanical operation of the machine to recognize a malfunction or potential malfunction. 3121641 – JLG Lift –...
  • Page 24: 2.2 Preparation, Inspection, And

    NOTICE MAINTENANCE JLG INDUSTRIES, INC. RECOGNIZES A FACTORY-TRAINED SERVICE TECHNI- CIAN AS A PERSON WHO HAS SUCCESSFULLY COMPLETED THE JLG SERVICE The following table covers the periodic machine inspec- TRAINING SCHOOL FOR THE SPECIFIC JLG PRODUCT MODEL. tions and maintenance recommended by JLG Industries, Inc.
  • Page 25: Inspection And Maintenance Table

    At intervals as specified in the Service and Mainte- Owner, Dealer, or User Qualified JLG Mechanic Service and Maintenance Man- nance nance Manual. NOTE: Inspection forms are available from JLG. Use the Service and Maintenance Manual to perform inspections. 3121641 – JLG Lift –...
  • Page 26: Pre-Start Inspection

    SONNEL. DO NOT OPERATE THE MACHINE UNTIL IT IS DECLARED SAFE FOR legibility. Make sure none of the decals and placards OPERATION. are missing (refer to the Decal Installation in Section 3). Make sure all illegible decals and placards are cleaned or replaced. – JLG Lift – 3121641...
  • Page 27 SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION Figure 2-1. Walk Around Inspection Diagram 3121641 – JLG Lift –...
  • Page 28: General

    10. Leveling Jack Valve (If equipped) - No unsupported tioned. wires or hoses; no damaged or broken wires. NOTE: All wheel lugs are to be torqued at 170 ft lbs (240 Nm). Figure 2-2. Walk Around Inspection Points - Sheet 1 of 2 – JLG Lift – 3121641...
  • Page 29 16. Battery Cables/Routing Installation - See Note. Note. 17. Drive Header Valve (4WD only) (If applicable) - See Note. 18. Rotary Switch - See Note. Figure 2-3. Walk Around Inspection Points - Sheet 2 of 2 3121641 – JLG Lift –...
  • Page 30: Function Check

    ControlS, Indicators and Operation, See Table 2-2 3394RT/4394RT 5° to full height 3° to full height and Table 2-3; (CE) d. Ensure that all machine functions are disabled when the Emergency Stop Button is activated. – JLG Lift – 3121641...
  • Page 31: Lockout Cylinder Test

    3. Set the DRIVE control switch into position and care- fully drive the machine up ascension ramp until left oscillating axle wheel is on top of block. 4. Verify the axle oscillates to maintain contact with the ground/ramp. (All four wheels on the ground). 3121641 – JLG Lift –...
  • Page 32 Right Side Wheel Test approximately 9 ft (2.7 m) on the 3394RT or 10 ft (3.1 m) on the 4394RT. 1. Place a 4 inch (10.16 cm) high block with ascension ramp in front of right wheel of the oscillating axle.
  • Page 33: Dual Fuel System (If Equipped)

    FOLLOWING INSTRUCTIONS MUST BE FOLLOWED. Changing from Gasoline to LP Gas: 1. Start the engine from the ground control station. 2. Open the hand valve on the LP Gas supply tank by turning counterclockwise. 3121641 – JLG Lift – 2-11...
  • Page 34 SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION AND INSPECTION NOTES: 2-12 – JLG Lift – 3121641...
  • Page 35: Section 3 - Machine Controls, Indicators And Operation

    SINCE THE MANUFACTURER HAS NO DIRECT CONTROL OVER MACHINE APPLI- The JLG Scissor Lift has a primary operator Control Station CATION AND OPERATION, CONFORMANCE WITH GOOD SAFETY PRACTICES IN in the platform. From this Control Station, the operator can...
  • Page 36: Operating Characteristics And Limitations

    Placards Stability Important points to remember during operation are pro- This machine, as originally manufactured by JLG and oper- vided at the control stations by DANGER, WARNING, CAU- ated within its rated capacity on a smooth, firm and level TION, IMPORTANT and INSTRUC TION placards. This...
  • Page 37 5. Platform Manual Descent T-Handle 2. Ground Control Station 6. Platform AC Receptacle Plug 3. Fuel/Hydraulic Compartment 7. Scissor Arms - Safety Prop 4. Engine/Pump/Battery Compartment 8. Manual Storage Box Figure 3-1. Location of Machine Controls. (All Models) 3121641 – JLG Lift –...
  • Page 38: 3.4 Ground Controls And Indicators

    6. Power Deck (Rear) (If equipped) 7. Auxiliary Power (If equipped) 8. Water Temperature 9. Hourmeter 10. Oil Pressure 11. Lift 12. Battery 13. Start 14. Platform Overload Indicator (If equipped) Figure 3-2. Ground Control Station – JLG Lift – 3121641...
  • Page 39: Ground Control Station

    The ground control emergency stop switch tor switch positioned to ground, fur- provides power to the key switch. With the power nishes operating power to the ground select switch in the center off position, power is shut 3121641 – JLG Lift –...
  • Page 40 14. Platform Overload Indicator (If equipped) - Illuminates when the plat- form becomes overloaded. 9. Hourmeter - The machine is equipped with an hour meter to indicate the number of hours the machine has been operated. – JLG Lift – 3121641...
  • Page 41: Manual Descent Control

    The T-handle is connected, by a cable, to the manual descent valve on the lift cylinder. Pulling the manual descent handle opens the valve spool, lowering the platform. Manual Descent Control - T-Handle Location 3121641 – JLG Lift –...
  • Page 42: 3.5 Platform Control Station

    10. Emergency Stop Switch 11. Drive Select 12. Horn Button 13. Start Switch 1705913B 14. Turn Signal Switch (Option) 15. Head/Tail Lights Switch (Option) TURN SIGNAL LEFT RIGHT 1001110553 A 1705914B Figure 3-3. Platform Control Station – JLG Lift – 3121641...
  • Page 43: Platform Controls

    On a machine equipped with a diesel pletely lowered. Use the following instructions to adjust engine this switch serves as a glow the level of the machine. plug switch. 3121641 – JLG Lift –...
  • Page 44 The speed on all a. Control Handle - The control handle controls five selected functions, (except leveling jacks), is pro- functions: drive, lift, power deck, leveling jacks portionally controlled by the distance of travel of 3-10 – JLG Lift – 3121641...
  • Page 45 Low/High switch and the dis- tion controls in the event of an emergency. With the 3121641 – JLG Lift – 3-11...
  • Page 46: Indicator Control Panel

    14. Turn Signal Switch (Option) - This switch when pushed for- ward to front of machine 3-12 – JLG Lift – 3121641...
  • Page 47 1. Power Deck 2. Drive 3. Lift 4. Fuel Gauge 5. Tilt 6. System Fault 7. Leveling Jacks Fully Retracted 8. Leveling Jacks Operational 9. Leveling Jacks Set 1705189A 170 539 0A Figure 3-4. Indicator Panel 3121641 – JLG Lift – 3-13...
  • Page 48: Engine Operation

    For high speed (Rabbit), Mid Speed (White Line) and FORM IS RAISED ABOVE THE STOWED POSITION. Low Speed (Turtle). All three speeds will work with the drive function. The high speed select will not operate the lift func- tion. 3-14 – JLG Lift – 3121641...
  • Page 49: Starting Procedure

    IF ENGINE FAILS TO START PROMPTLY, DO NOT CRANK FOR AN EXTENDED PERIOD. SHOULD ENGINE FAIL TO START ONCE AGAIN, ALLOW STARTER TO “COOL OFF” FOR 2 TO 3 MINUTES. IF ENGINE FAILS TO START AFTER SEVERAL ATTEMPTS, REFER TO ENGINE MAINTENANCE MANUAL. 3121641 – JLG Lift – 3-15...
  • Page 50: 3.7 Dual Fuel System

    The load should be runs smoothly on gasoline. placed near the center of the platform when possible. 3. Close the hand valve on the LPG supply tank by turn- ing clockwise. 3-16 – JLG Lift – 3121641...
  • Page 51: Traveling (Driving)

    1. Position the emergency stop switch at the platform control station to the on position. the wheels are centered. 2. Press the drive switch and move the control handle backward (reverse) and hold for the duration of travel. 3121641 – JLG Lift – 3-17...
  • Page 52 SECTION 3 - MACHINE CONTROLS, INDICATORS AND OPERATION Figure 3-5. Grade and Sideslope 3-18 – JLG Lift – 3121641...
  • Page 53: Leveling Jacks

    If there is a proximity switch time is allowed for all leveling adjustments to be com- failure or elevation sensor failure, the leveling jacks func- pleted. tion is locked out. 3121641 – JLG Lift – 3-19...
  • Page 54: Manual Level Adjustment (Trim)

    NOTE: You can not adjust the level of the machine with the EASI- switch is not activated within 5 seconds after the trig- CLADDER™ option installed. ger switch is pressed, power is removed from the cir- 3-20 – JLG Lift – 3121641...
  • Page 55: Lowering

    NOTE: There is a 5 second time out after the joystick is released. If one extension is selected and released the opposite deck extension cannot be selected for 5 seconds. 3121641 – JLG Lift – 3-21...
  • Page 56: Auxiliary Power

    BE SURE AND RETRACT ANY POWER DECK BEFORE LOWERING MACHINE. the auxiliary power. Generator When the generator switch is activated the engine RPM will speed up. When the joystick is triggered the generator will shut off. 3-22 – JLG Lift – 3121641...
  • Page 57: Parking And Stowing

    NOTE: If lifting becomes necessary from the lifting lugs, JLG 6. Turn the power selector switch to off and remove the Industries Inc. recommends the use of a proper spreader key to disable the machine and prevent unauthorized bar to avoid damage to the machine.
  • Page 58 SECTION 3 - MACHINE CONTROLS, INDICATORS AND OPERATION WHEELBASE MODEL(S) (in) (cm) (in) (cm) (in) (cm) 3394/4394RT Figure 3-6. Lifting and Tie Down Chart (Sheet 1 of 2) 3-24 – JLG Lift – 3121641...
  • Page 59 SECTION 3 - MACHINE CONTROLS, INDICATORS AND OPERATION Figure 3-7. Lifting and Tie Down Chart (Sheet 2 of 2) 3121641 – JLG Lift – 3-25...
  • Page 60 SECTION 3 - MACHINE CONTROLS, INDICATORS AND OPERATION NOTES: 3-26 – JLG Lift – 3121641...
  • Page 61: Section 4 - Emergency Procedures

    The following procedures are to be used ONLY for emergency movement to a suitable maintenance area. 1. Chock wheels securely. 2. Disengage drive hubs by reversing disconnect caps. 3. Connect suitable equipment, remove chocks, and move machine. 3121641 – JLG Lift –...
  • Page 62: Emergency Controls And Their Locations

    Place the power select switch in the ground posi- tion and operate the lift switch to lift up or down. Manual Descent Control - T-Handle Location – JLG Lift – 3121641...
  • Page 63: Emergency Operation

    3121641 – JLG Lift –...
  • Page 64: Incident Notification

    It is imperative that JLG Industries, Inc. be notified immedi- hours of such an occurrence may void any warranty con- ately of any incident involving a JLG product. Even if no sideration on that particular machine. injury or property damage is evident, the Product Safety...
  • Page 65: Section 5 - General Specifications And Operator Maintenance

    The vibration total value to which the hand-arm system is Illustrated Parts Manual ............3121643 subjected does not exceed 2,5 m/s2. The highest root mean square value of weighted acceleration to which the whole body is subjected does not exceed 0,5 m/s2. 3121641 – JLG Lift –...
  • Page 66: Operating Specifications

    3.5 mph (5.6 kph) 3.5 mph (5.6 kph) Electrical System Voltage 12 Volt LIft Up Speed 32 - 39 seconds 40 - 45 seconds (Stowed to Full Height) Inside Turning Radius 8 ft 10.5 in (2.71 m) – JLG Lift – 3121641...
  • Page 67: Dimensional Data

    15,240 lbs (6,913 kg) Capacities w/Two Extensions 13,440 lb. (6,096 kg) 15,780 lbs (7,158 kg) Table 5-3. Capacities Note: Certain options or country standards increase weight. Fuel Tank 31.5 gal (119.2 L) Hydraulic Tank 32.3 gal (122.2 L) 3121641 – JLG Lift –...
  • Page 68: Tires

    (238 Nm) 33/16LLx16.1 170 ft lbs Foam Filled - Sand (238 Nm) 60 psi 170 ft lbs 31 x 15.50-15 (4 bar) (238 Nm) IN315/55D20 75 psi 170 ft lbs Pneumatic (5 bar) (238 Nm) – JLG Lift – 3121641...
  • Page 69: Engines

    High RPM 1.6 GPH (6.0 lph) Displacement 2.9L - 2925 cm (179 cu. in.) Horsepower 49 Hp (36.4 Kw) @ 2600 RPM Torque Rating 108 Ft. lb. (147 Nm) @ 1600 rpm Cylinder Firing Order 1-3-4-2 3121641 – JLG Lift –...
  • Page 70: Critical Stability Weights

    441 lbs (200 kg) at operation 18 psi (1.2 Bar) @ 2000 rpm Engine (GM) 341 lbs (155 kg) Compression Ratio 9.2:1 Tier/Stage 3 10.25:1 Battery 65 lbs (30 kg) Firing Order 1-3-4-2 Maximum RPM 2800 – JLG Lift – 3121641...
  • Page 71: Lubrication

    152. sel - (T4F - API CJ-4), API CJ-4/CG-4 class, ACEA E3-90/E5-02. NOTE: When temperatures remain below 20° F (-7° C), JLG Indus- tries recommends the use of Mobil DTE13. NOTE: Aside from JLG recommendations, it is not advisable to...
  • Page 72 SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Figure 5-1. Engine Oil/Diesel Fuel - Operating Temperature Specifications - Deutz - Sheet 1 of 2 – JLG Lift – 3121641...
  • Page 73: Specifications - Deutz - Sheet 2 Of 2

    SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Figure 5-2. Hydraulic Oil - Operating Temperature Specifications - Deutz - Sheet 2 of 2 3121641 – JLG Lift –...
  • Page 74: Specifications - Gm - Sheet 1 Of 2

    -20°F (-29°C) FLUIDS, A FULL Y CHARGED BA TTER Y AND THE AID OF A COMPLETE JLG SPECIFIED COLD WEA THER P ACKAGE (IE. ENGINE BLOCK HEA TER, BA TTER Y W ARMER AND HYDRAULIC OIL T ANK HEA TER) -30°F (-34°C)
  • Page 75: Specifications - Gm - Sheet 2 Of 2

    SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Figure 5-4. Hydraulic Oil - Operating Temperature Specifications - GM - Sheet 2 of 2 3121641 – JLG Lift – 5-11...
  • Page 76: Operator Maintenance

    To store the safety prop, raise the platform, push the safety prop handle so that the prop can be restored back to its stowed position. TO AVOID PERSONAL INJURY, USE SAFETY PROP FOR ALL MAINTENANCE REQUIRING PLATFORM TO BE ELEVATED. 5-12 – JLG Lift – 3121641...
  • Page 77: Operator Maintenance Components

    10. Electronic Pressure Regulator (LP Only) 3. Hydraulic Oil Tank 7. Fuel Filter - Deutz 11. Fuel Filter (Propane) - GM 4. Sliding Wear Pads 8. Fuel Filter (Gasoline) - GM Figure 5-5. Operator Maintenance Components (All Models) 3121641 – JLG Lift – 5-13...
  • Page 78: Fuel Tank

    • Fuel - Diesel or Gasoline (Per Engine Type - Reference • Lube - EPGL Decal on Machine) • Interval - Every 2 years or 1200 hours • Capacity - 31.5 gal (119 l) 5-14 – JLG Lift – 3121641...
  • Page 79: Hydraulic Oil

    • Interval - Every Year or 600 hours of operation • Comments - Check level daily/Change in accordance • Lube Points - 8 Sliding Wear Pads with engine manual. • Lube - MPG • Interval - Every month or 50 hours. 3121641 – JLG Lift – 5-15...
  • Page 80: Oil Change W/Filter - Deutz D 2.9 L4 - T4F

    • Interval - Every Year or 600 hours of operation • Interval - 3 Months or 150 hours of operation • Comments - Check level daily/Change in accordance • Comments - Check level daily/Change in accordance with engine manual. with engine manual. 5-16 – JLG Lift – 3121641...
  • Page 81: Fuel Filter - Deutz

    Pre-Filter with pressure sensor next to fuel tank • Interval - Every Year or 600 hours of operation Fuel Filter (Gasoline) - GM Engine • Lube Point(s) - Replaceable Element • Interval - Every 6 months or 300 hours of operation 3121641 – JLG Lift – 5-17...
  • Page 82: Air Filter

    • Comments - Replace filter. Refer to Section 5.6, Propane Fuel Filter Replacement • Interval - 3 Months or 150 hours of operation • Comments - Drain oil build up. Refer to Section 5.5, Draining Oil Build Up from the Propane Regulator 5-18 – JLG Lift – 3121641...
  • Page 83: Draining Oil Build Up From The Propane

    5. Disconnect the electrical connection to the LPG fuel 2. Start the engine and bring to operating temperature. temperature sensor in the auxiliary fuel port of the EPR. 3121641 – JLG Lift – 5-19...
  • Page 84 8. Open the fuel tank manual valve. 9. Start the engine and verify all connections are secure. 10. Dispose of any drained oil per local regulations in a safe and proper fashion. 5-20 – JLG Lift – 3121641...
  • Page 85: Propane Fuel Filter Replacement

    BE SURE TO REINSTALL THE FILTER MAGNET INTO THE HOUSING BEFORE 6. Seal 12. Retaining Bolt INSTALLING NEW SEAL. Figure 5-6. Filter Lock Assembly 1. Install the mounting plate to lock off O-ring seal. 3121641 – JLG Lift – 5-21...
  • Page 86: Propane Fuel System Pressure Relief

    Refer to Section 5.8, Propane Fuel System Leak Test. 3. Turn the ignition switch OFF. RESIDUAL VAPOR PRESSURE WILL BE PRESENT IN THE FUEL SYSTEM. ENSURE THE WORK AREA IS WELL VENTILATED BEFORE DISCONNECTING ANY FUEL LINE. 5-22 – JLG Lift – 3121641...
  • Page 87: Propane Fuel System Leak Test

    JLG product from service immediately and arrangements must be made for replace- ment of the tire or tire assembly: •...
  • Page 88: Tire Replacement

    JLG Parts Manual for the part number of the approved width, tire pressure, and load capacity. Size changes such tires for a particular machine and model. If not using a JLG as rim width, center piece location, larger or smaller diam- approved replacement tire, we recommend that replacement eter, etc., without written factory recommendations, may...
  • Page 89: Wheel Torque Chart

    Following the recommended sequence, tighten the nuts per wheel torque chart. Wheel nuts should be torqued after the first 50 hours of operation and after each wheel removal. Check torque every 3 months or 150 hours of operation. 3121641 – JLG Lift – 5-25...
  • Page 90: 5.10 Decal Installation

    SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE 5.10 DECAL INSTALLATION Figure 5-7. Decal Location - Sheet 1 of 2 (ANSI) 5-26 – JLG Lift – 3121641...
  • Page 91: Decal Location - Sheet 2 Of 2 (Ansi)

    SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Leveling Jacks (if equipped) Figure 5-8. Decal Location - Sheet 2 of 2 (ANSI) 3121641 – JLG Lift – 5-27...
  • Page 92: Decal Location Legend - Ansi

    1701509 1701509 1701509 1701509 1703811 1703811 1703811 1703811 1703811 1703811 1703812 1703812 1703812 1703812 1703812 1703812 1703814 1703814 1703814 1703814 1703814 1703814 1704277 1704277 1704277 1704277 1704277 1704277 1703819 1703819 1703819 1703819 1703819 1703819 5-28 – JLG Lift – 3121641...
  • Page 93 1704702 1001162112 1705019 1705019 1705019 1705019 1705019 1705019 1704432 1705943 1705311 1705316 1705318 1001162113 1703823 1705944 1705040 1705041 1705043 1001162114 3394RT 1705038 1705038 1705038 1705038 1705038 1705038 4394RT 1705039 1705039 1705039 1705039 1705039 1705039 3121641 – JLG Lift – 5-29...
  • Page 94 1701542 1701542 1701542 1701542 1701505 1701505 1701505 1701505 1701505 1701505 1702788 1702788 1704174 1704174 1702962 1702962 1702961 1702961 1704690 1701214 1701214 1704697 1704698 1701214 1701214 1705042 1705042 1705042 1705042 1705042 1705042 1001108923 1001108923 1001108923 5-30 – JLG Lift – 3121641...
  • Page 95: Decal Installation - Sheet 1 Of 2 (Ce/Aus)

    SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Figure 5-9. Decal Installation - Sheet 1 of 2 (CE/AUS) 3121641 – JLG Lift – 5-31...
  • Page 96: Decal Installation - Sheet 2 Of 2 (Ce/Aus)

    SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Leveling Jacks (if equipped) Figure 5-10. Decal Installation - Sheet 2 of 2 (CE/AUS) 5-32 – JLG Lift – 3121641...
  • Page 97: Decal Legend - Ce/Aus

    1 - 3 22 - 30 1700584 1702773 1702631 1704885 1705515 3251813 1703687 1703162 1704412 1706338 3252533 1705019 3252534 1705671 11-14 1705372 1701509 1703811 3394RT 1705038 4394RT 1705039 1703812 1703493 1703814 1701505 1704277 1703819 3121641 – JLG Lift – 5-33...
  • Page 98 SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE Table 5-13. Decal Legend - CE/AUS CE/AUS Item # (0275086-2) 1702788 1703479 1704174 1704175 1702962 3394RT 1705034 1705035 4394RT 1705036 1705037 1701785 1705042 5-34 – JLG Lift – 3121641...
  • Page 99: Section 6. Inspection And Repair Log

    SECTION 6 - INSPECTION AND REPAIR LOG SECTION 6. INSPECTION AND REPAIR LOG Table 6-1. Inspection and Repair Log Date Comments 3121641 – JLG Lift –...
  • Page 100 SECTION 6 - INSPECTION AND REPAIR LOG Table 6-1. Inspection and Repair Log Date Comments – JLG Lift – 3121641...
  • Page 104 +61 2 65 810122 +44 (0)161 654 1001 JLG Deutschland GmbH JLG Equipment Services Ltd. JLG Industries (Italia) s.r.l. Oshkosh - JLG Singapore T. E. P. Ltd. Max-Planck-Str. 21 Rm 1107 Landmark North Via Po. 22 29 Tuas Ave 4...
