For your safety

Explanation of icons

2.2 Explanation of icons
Symbol Description
Indicates technical aspects which the
user must observe.
Switch off machine
Switch on machine
Wrong
Correct
Menu entry
Navigating the menu
Exit menu
Time representation (e.g.: wait
4 s/activate)
Interruption in the menu display (other
setting options possible)
Tool not required/do not use
Tool required/use
6
Symbol Description
Activate and release/tap/tip
Release
Press and keep pressed
Switch
Turn
Numerical value – adjustable
Signal light lights up in green
Signal light flashes green
Signal light lights up in red
Signal light flashes red
099-000181-EW501
30.06.2017
