Design and function
Transport and installation
5.1.6
TIG cold wire welding
AC
5.1.6.1
Legend
Shielding gas
Welding current (minus potential)
Welding current (plus potential, workpiece)
Coolant inlet (colour-coded)
Coolant outlet (colour-coded)
Hose package (HP = hose package)
HP
18
1~
AC
tigSpeed drive 45 coldwire
HP
Figure 5-6
HP
3~
AC
Tetrix
TIG 450W CW 12POL
AC
099-000181-EW501
30.06.2017
