Machine description – quick overview
Rear view
Item Symbol
13
14
15
16
17
4.2
Rear view
Item Symbol
1
2
3
4
5
10
Description
0
Cooling air outlet
Quick connect coupling
Shielding gas
Connection socket (TIG)
Welding current, minus potential
Connection socket (12-pole)
Welding torch control lead
Wire electrode connection
Welding torch wire feed
Description
0
Connector plug, 5-pole
Control lead
Machine fuse (6,3 A)
Main switch, machine on/off
Connector plug (TIG)
Welding current, minus potential
Connecting nipple G¼, shielding gas connection
Figure 4-2
099-000181-EW501
30.06.2017
