Machine control – Operating elements
4.3
Operating elements that are not listed have no function!
099-000181-EW501
30.06.2017
Machine description – quick overview
Description
0
Mains connection cable > see 5.1.7 chapter
Cooling air inlet
External wire feed inlet
Pre-cut casing inlet for external wire feed.
Quick connect coupling (red)
coolant return
Quick connect coupling (blue)
coolant supply
Machine control – Operating elements
Figure 4-3
