wiring and connectors for attachment to wire harnesses. The panel is built to match the horsepower,
voltage, phase and frequency of the customer's requirements.

6.2.1 Wiring Diagram

The wiring diagram for your specific Compressor Unit is stored inside the Electrical Panel. If a wiring
diagram for your machine is not found inside the Electrical Panel, then please call Bauer Compressors
Product Support Group for a replacement. Please have the serial number of the compressor available; it
is written on a label (See Figure 6-2) inside the Electrical Panel door.
6.2.2 Electrical Panel Interior Access
The interior of the Electrical Panel is accessed by using a coin or screwdriver to turn the latch on the
front of the Electrical Panel.
6.2.3 Optional Equipment
Optional equipment which may also be housed in the Electrical Panel is any of five Communication
Modules. An EEPROM Memory Module may also be an option in the Electrical Panel.
6.3 AC Power Requirements
The Electrical Panel must be supplied with electricity of the correct voltage, phase, and frequency to
ensure proper operation. Wiring and conduit selection must be in accordance with all national, state and
local codes. The customer is responsible for providing a means of disconnection from the power source
and protection from instantaneous short circuit. The Electrical Panel voltage and phase are displayed on
the exterior of the Electrical Panel as well as being written on a label (See Figure 6-2) on the inside of
the Electrical Panel door. In this example shown, the panel is wired for 230 volt, single phase, serial
number 100210.
Page 76
Electrical Panel Label
Figure 6-2
Norfolk, VA 23502 USA
757-855-6006 www.bauercomp.com
UL File No. E141433
ASY-1058
PANEL:
Short Circuit Current:
MAXIMUM RATING (AC3)
1 Ph 60 Hz
230V
10 HP
46 FLA
VE-13-E1/230V
MODEL:
100210
SERIAL:
P0808762/06
BLOCK:
MFG DATE: 2/2009
Use 600 VAC and 60 Degree Celsius
Copper Wire Only
xx,xxx
Wire Range
Terminal
KA
Line awg 10-3
Ground awg 14-2
CONTROL FUSE LEGEND
1FU
2FU
ATQR - ATQR -
3A 3A
G 120 II V
Torque
45 in-lb
35 in-lb
3FU
TRM -
2A
1st Edition, Rev. 0 Chg. 2
