3.3.1 Condensate Collector Replacement Parts List
Condensate Collector
Figure 3-35
Item Qty
Part No.
1
1
CAP-0056
2
1
GKT-0065
3
2
ELM-0160
4
2
ELM-0161
5
1
HUS-0050
6
1
HUS-0060
7
1
SWT-0265
8
1
TNK-0092
9
1
RED-0067
10
1
VAL-0437
11
1
PLU-0198
12
1
MFD-0035
April 4, 2013
12
11
Description
Condensate Collector Cover
Gasket
Fine Filter Element
Coarse Filter Element
Condensate Collector, Inner
Condensate Collector, Outer
Float Switch
Condensate Collection Tank
Reducer
Manual Drain Valve
Plug
ACD Manifold
1
2
3
4
5
6
7
8
9
10
Notes
Page 55
