4.2 P1 Purification System

4.2.1 Major Components
The P1 Purification System major components are a Oil and Water Separator and a Purification Chamber.
Figure 4-6 shows the functional interconnection of all the components.
Figure 4-6
IN
1. Oil and Water Separator
2. Condensate Drain Valve
3. Check Valves
4. Chamber
April 4, 2013
P1 Purification System
7
3
2
1
4 5
5. Bleed Valve
6. Pressure Maintaining Valve
7. Safety Valve
OUT
6
3
