CHAPTER 5: SETTINGS

5.5.7 Phasor Measurement Unit

5.5.7.1 Menu
SETTINGS  SYSTEM SETUP  PHASOR MEASUREMENT UNIT
 PHASOR MEASUREMENT
 UNIT
The D60 is provided with an optional Phasor Measurement Unit (PMU) feature. This feature is specified as a
software option at the time of ordering. The number of PMUs available also depends on this option. Using the
order code for your device, see the order codes in chapter 2 for details.
5.5.7.2 UR synchrophasor implementation
Phasors are used in protection relays. When these phasors are referenced to a common time base, they are referred to as
synchrophasors. A vastly improved method for tracking power system dynamic phenomena for power system monitoring,
protection, operation, and control can be realized when synchrophasors from different locations within the power system
are networked to a central location.
The D60 offers PMU features over two communication standards, IEC 61850-90-5 and IEEE C37.118. The figure shows
complete synchrophasor implementation.
D60 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL
Figure 5-85: Recloser curves GE119, GE135, and GE202
 PHASOR MEASUREMENT

 UNIT 1
 PMU AGGREGATOR 1


 IEC 90-5 MSVCB

 CONFIGURATION
See below
See page 5-182
See page 5-184
