Table 1: Steval-Isb044V1 Electrical Performance: Input Characteristics; Table 2: Steval-Isb044V1 Electrical Performance: System Characteristics; Figure 3: Steval-Isb044V1 Evaluation Board: Connectors, Leds And Test Points - ST STEVAL-ISB044V1 User Manual
Getting started with the qi mp-a10 wireless charger tx
evaluation board based on stwbc-ep
Table of Contents
Advertisement
UM2301
Parameter
Vin
Iin
Parameter
Fs
Duty cycle
ƞ
Figure 3: STEVAL-ISB044V1 evaluation board: connectors, LEDs and test points
Table 1: STEVAL-ISB044V1 electrical performance: input characteristics
Input
characteristics
Input voltage
Input current
Input no-load current
Input stand-by
current
Table 2: STEVAL-ISB044V1 electrical performance: system characteristics
Input characteristics
Switching frequency
Duty cycle modulation
Full load efficiency
DocID031141 Rev 1
Min.
Typ.
Max.
Unit
5
12
13
V
1.6
2
A
mA
1.4
mA
Min.
Typ.
Max.
110
180
5
50
80
Hardware description and setup
Notes and conditions
Vin nominal, Iout = max. on MP1B
Rx
At typical voltage
Unit
Notes and conditions
kHz
Decrease with load
%
Duty cycle
%
Vin= 12 V, P Out Rx = 15 W
9/57
