GUI and evaluation procedure

Through the GUI, you can change the parameters and produce a new cab to program a

batch of new boards. To this aim, dump the parameters into a bin file, but only after clicking

the Push to target button.

You can then select Modify parameters in CAB file from the setup menu and select the

appropriate firmware CAB file to be patched. This operation will alter the firmware file with

new tuning parameters, which can be subsequently loaded using the standard procedure.

32/57

Figure 38: STSW-STWBCGUI: saving modified parameters (Dump to bin)

DocID031141 Rev 1

UM2301
