UM2301
Four files will be generated as shown below.
3.6
Firmware download with STVP
1
Power the target off.
2
Power the target on.
3
Connect ST-LINK circuit to the PC via USB.
4
Connect the ST-LINK–SWIM cable to the target.
5
Launch STVP software.
Figure 26: STVP project file name
Figure 27: STVP files created
Pay special attention in connecting the SWIM cable to the transmitter
board correctly, as shown in
board: ST-LINK
connection".
DocID031141 Rev 1
Figure 17: "STEVAL-ISB044V1 evaluation
Download procedure
23/57
