Current sensing and demodulation

54/57

Figure 66: STEVAL-ISB044V1 evaluation board: current sensing

VRSENSE
R307
0.022R
Direct GND line connection
Warning:
R308 GND is done through
a trace connected to GND
on Rsense R307
Don't mix this track with
ground plane

Figure 67: STEVAL-ISB044V1 evaluation board: current demodulation

U501
R517
1 +IN
IDEMOD
+
1M 2 V-
3 -IN -
TSV521ICT
C513
C512
22PF
100NF
3
R520
330R
Current demod (U501, R and C) near
Current amplifier output (Q301)
12
CURRENT_DEMOD
CURRENT_DEMOD
TANK_VOLTAGE
15
TANK_VOLTAGE
16
VTARGET
17
QFOD_ADC
18
COIL_TEMP
19
ISENSE
20
VMAIN
DocID031141 Rev 1
