Download procedure
6
Select STM8AF6166 as core (see
7 In STVP, open the Project menu and click Open.
8
Select the .stp given in the zip file.
9
Wait few seconds.
The following message should appear:
Loading file program.hex in PROGRAM MEMORY area...
< File successfully loaded. File Checksum 0x1D1205
10 In STVP, open the Program menu and select All tabs (on active sectors, if any)
11
Click OK if a "wrong device selected" alert appears (see
device selected
12
Click YES if "An incompatibility has been found with this device" alert appears (see
Figure 21: "STVP incompatibility device action
After this operation, the programming procedure starts. At completion, the STVP
informs the user that the program is loaded and verified.
24/57

Figure 28: STVP file selection

It is normal that some warnings appear:
> Loading file options.hex in OPTION BYTE area...
FILE : line 2: Address 0x4802 is out of range and is ignored!
FILE : line 2: Address 0x4804 is out of range and is ignored!
alert").
DocID031141 Rev 1
Figure 18: "STVP core
query").
UM2301
selection").
Figure 20: "STVP wrong
