Hitachi CM 75EAP Service Manual page 38

PARTS
ITEM
CODE NO.
NO.
51 6699899 PULLEY (B)
52 948391 RETAINING RING FOR D40 HOLE
53 6203DD BALL BEARING 6203DDCMPS2L
54 6699880 BB COLLAR
55 6699879 FELT
56 6699896 BOLT M5 (S)
57 6699895 WHEEL GUARD SPRING
58 949566 LOCK NUT M5 (10 PCS.)
59 949425 WASHER M6 (10 PCS.)
60 6699850 SPRING HOLDER
61 6699881 CHAIN BAR BOLT
62 6699176
HEX. SOCKET HD. BOLT (W/SP.WASHER) M5 X 12
63 6600367 ARM
64 6699883 STOPPER HOLDER
65 6600368 STOPPER RUBBER
66 6699866 COLLAR
67 6600396 ARM PLATE
68 6696836 HEX. SOCKET HD. BOLT M5 X 12 (PRECOAT)
69 6699885 PLATE (A)
70 6699886 DAMPER (A)
71 6699889 SET BOLT M5 X 16
72 6699888 HANDLE (W)
73 6699892 CAP NUT
74 6699891 WATER SUPPLY JOINT (B)
75 6699912 LOCK NUT
76 6699911 WATER SUPPLY HOSE
77 6699893 NOZZLE BOLT
78 996399 HEX. SOCKET HD. BOLT (W/FLANGE) M5 X 12
79 6600375 STOPPER HOLDER (B)
80 6699887 WHEEL GUARD (12")
81 6600376 WHEEL MARK LABEL (12")
82 6699890 WATER SUPPLY JOINT (A)
83 6699894 FLANGE (A)
84 6699882 SPINDLE
85 6699897 WHEEL WASHER
86 6699898 SPINDLE COLLAR
87 6699901 FLANGE WASHER
101 6600369 TANK CAP
102 6685179 TANK CAP PACKING
103 6699828 SQUARE NUT M5
104 6685139 PRIMING PUMP COMP.
105 6698722 FUEL PIPE
106 6699837 FUEL PIPE (PINK)
107 304035
TAPPING SCREW (W/FLANGE) D4 X 25 (BLACK)
* 108 6698921 TANK MARK LABEL (50:1)
* 108 6698922 TANK MARK LABEL (25:1)
109 305812
TAPPING SCREW (W/FLANGE) D4 X 16 (BLACK)
110 6699838 AIR VENT CAP
111 6600370 INNER CAP (B)
112 6698931 FUEL GROMMET
- 4 -
DESCRIPTION
*ALTERNATIVE PARTS
NO.
REMARKS
USED
1
1
2
1
1
3
3
8
3
2
2
5
1
1
2
6
1
4
2
2
2
1
2
1
4
1
2
1
1
1
1
1
1
1
2
1
1
1 INCLUD.102
1
4
1
1
1
1
1
1 FOR ASIA
8
1
1
1
CM 75EAP
9 - 14
